Description
Standard Equipment
- Vertical offset, cast iron housing
- 7° down angle on output shaft
- Mechanical control valve
- Oil strainer
Options
- SAE J617 no. 2 to SAE J617 no. 1 housing adaptor
- SAE J617 housing no. 2
- SAE J617 housing no. 3
- SAE J617 housing no. 4
- Flexible coupling for 14” flywheel (SAE J620 size 355)
- Flexible coupling for 11.5” flywheel (SAE J620 size 290)
- Flexible coupling for 10” flywheel (SAE J620 size 255)
- Input flange for freestanding installation
- Electric control valve (12VDC or 24 VDC)
- Mechanical trolling valve
- Oil cooler
- Companion flange/ bolts set
- Monitoring devices to customer’s specification
- Mounting brackets
- Live PTO:
- SAE J744 size 82-2, 16-4 (SAE “A”, 2-bolt, max. 35 Nm)
- SAE J744 size 101-2/4, 22-4 (SAE “B”, 2/4-bolt, max. 197 Nm)
| Reduction Ratios :1 |
Pleasure Craft @ 2500 RPM |
Light Duty @ 2300 RPM |
Intermediate Duty @ 2100 RPM |
Medium Duty @ 1800 RPM |
Continuous Duty @ 1800 RPM |
|---|---|---|---|---|---|
