• Cylinder Arrangement: Inline 6 Cylinder
• Air Feeding: TCA
• Displacement: 8.7 L
• Injection System: ECR
Available in the following power rating configurations:
High Performance Crafts – Maximum usage 300 hours per year.
• A1 : 650HP @ 2530rpm
| Weight | 2072 lbs |
|---|---|
| Dimensions | 50.7 × 32.4 × 37.8 in |
| Type | Diesel 4 Stroke |
| Configuration | Inline 6 Cylinder |
| Air Handling | Turbocharged Air Cooled |
| Bore X stroke | 117 x 135 mm |
| Displacement | 8.7 L |
| Compression Ratio | 14.5 : 1 |
| Valves per Cylinder | 4 |
| Rotation | CCW |
| Fuel System | Electronic Common Rail |
| Cylinder Head Material | Cast Iron |
| Over Head Camshaft | Heat Treated Steel |
| Piston | Aluminum Double Lip Re-entrant |
| Moment of Inertia | 1.880 kg/m2 |
| Temperature Regulation | 72-80C |
| Cold Start Aid | Yes |
| Emissions Level | EPA Tier 3 |
| Flywheel SAE1 | 14" |
| Flywheel Housing | Aluminum, SAE 1 |
| Oil Sump | Aluminum 10 Degree Static |
| Voltage | 24V |
| Alternator | 90A |
| Starter | 5.5 kW |
| Dry Weight | 2072 lbs |
| Wet Weight | 2200 lbs |
